EPOXY RESIN-ENCAPSULATED MEDIUM VOLTAGE TRANSFORMER
EPOXY RESIN-ENCAPSULATED MEDIUM VOLTAGE TRANSFORMER
Designed to minimize environmental impact, noise emissions, and fire risk. Additionally, it offers lower installation and maintenance costs. Ideal for confined spaces, LEED-certified buildings, hospitals, hotels, and industrial facilities.
| Technical Data | |
|---|---|
| Power | From 25 to 3150 KVA |
| Nominal voltage H.V. | From 4.16kV to 33kV |
| Number of Terminals H.V. | 3/4 |
| Nominal voltage L.V. | 0.460/ 0.400-0.231/ 0.398-0.230/0.480kV |
| Number of Terminals L.V. | 8/7/6/4/3 |
| Connection Group | Dyn5 - Dyn11 - Dd6 - Dd0 - Yd5 - Yyn6 - Yyn0 |
| Frequency | 50/60 Hz |
| Connection | Delta/ Star |
| Construction and Environmental Characteristics | |
|---|---|
| Protection Degree | IP00/ IP21/ IP31 |
| H.V. Encapsulated | Yes |
| Installation Altitude | Yes/ No |
| Instalación | 1000 - 4500 meters above sea level |
| Normas para Diseño, Fabricación y pruebas | IEC 60076-11/ANSI IEEE C57.12 04 |
